Features/Advantages
ccurate humidity and temperature transmitters for clean rooms, harsh HVAC, and light industrial applications.
± 1.5% RH accuracy.
Easy to exchange probes on site.
Multiple calculation parameter options.
Two wire current (loop 4... 20 mA) or Modbus RTU output is optional.
TR11 series remote probe temperature and humidity transmitter TR11 can achieve accurate humidity and temperature measurement in clean rooms, harsh HVAC and light industrial applications. The shell has an IP65 protection level and is a remote probe that can be easily interchanged on site. The probe can be easily removed and replaced with a new probe without adjusting the transmitter. The transmitter can be connected to a PC for single point and multi-point calibration on site.
Product parameters |
|||
Measurement parameters |
temperature sensor |
PT1000/PT100 RTD F0.1 IEC 60751 |
|
measuring range |
−40...+80 °C |
||
+Accuracy at 20 ° C |
±0.2 °C/±0.1 °C |
||
temperature coefficient |
±0.01 °C/°C |
||
Relative humidity sensor |
Polymer capacitive type |
||
Humidity range |
0... 100 %RH |
||
Humidity accuracy (10... 30 ℃) |
±1.5 %RH (0...90 %RH) ±2.5 %RH (90...100 %RH) |
||
Stability in typical HVAC applications |
±0.5 %RH/年 |
||
Calculated humidity parameters |
Dew point/frost point, absolute humidity, wet bulb temperature, enthalpy value |
||
Measurement range of dew point temperature and wet bulb temperature |
-40...60 ℃ |
||
Measurement range of enthalpy value |
-40...460 kJ/kg |
||
Dew point accuracy (20 ℃) |
±0.5℃ |
||
Input and output |
input |
18...28 VDC <1W |
|
Current output |
4...20 mA（2 Wire based circuit power supply） |
||
External circuit voltage |
10...28V（RL=0Ω） 20...28V（RL=500Ω） |
||
Mechanical and environmental parameters |
Transmitter operating temperature |
-40... 60 ℃ without display screen -20... 60 ℃ with display screen |
|
Probe operating temperature |
-40...80 ℃ |
||
Shell material |
PC+GF（UL94-V0） |
||
Probe material |
Stainless steel 316 |
||
