BRWY01 data gateway is a relay device that connects BR Link wireless acquisition devices and continuous monitoring systems. It can connect up to 2 wired acquisition probes and 64 wireless acquisition devices. Suitable for applications such as environmental monitoring and spatial validation.
Unique BR Link self-organizing network wireless communication
The so-called self-organizing network technology refers to the automatic search and connection of wireless data recorders to nearby gateways or signal amplifiers with the best signal, without the need for configuration.
Signal extension technology: When the data logger is installed in a location where the gateway signal cannot reach, BR Link's unique signal relay function can set up a signal relay bridge between the data logger and the gateway, covering signal blind spots.
A gateway or relay device can transmit signals up to 100 meters indoors and 2000 meters outdoors without obstruction. Wireless communication is encrypted to ensure data integrity and security.
Integrity and continuity of data
The BRWY01 data gateway comes with 300000 sets of data cache. In the event of inability to connect to the server, the data will be temporarily stored in the cache and transmitted to the server when the network is restored.
Redundancy
Installing multiple BRWY01 data gateways in the same space can increase system redundancy. When one gateway fails or cannot connect to the server, the other gateways will automatically replace the original gateway's functions
